Introducing RS86620: High-Efficiency Half-Bridge Power-stage

The RS86620 is a compact TLGA device measuring 4mm x 5mm, designed for use in Server and Telecom applications that require high efficiency and small size.

It is a monolithic half-bridge that includes internal power MOSFETs and gate drivers, enabling it to achieve a continuous output current of 30A over a wide input supply range of 2.5V to 16V. The integration of driver and MOSFETs ensures high efficiency by reducing parasitic inductance and optimizing dead time.

This device can operate from 100kHz to 2MHz with a 12V input voltage and up to 3MHz with a 5V input voltage. It is compatible with tri-state output controllers and includes a general-purpose current sense and temperature sense, meeting industry specifications.

Key Features

• Wide 2.5V to 16V Operating Input Range
• 5V VDD supply for internal logic
• Integrated power stage with High/Low-side MOSFETs and Drivers
• 60A Max, 30A TDC Output Current
• Operation Frequency up to 3MHz with 5V VIN and 2MHz with 12V VIN.
• Compatible with 3.3V tri-state PWM input
• Internal Current Sense and Temperature Sense
• Built in Protection
  • Vin and VDD UVLO
  • High side Over Current Protection
  • Cycle-by-cycle Over Current Limit
  • Over Temperature Protection (OTP)
• Common Footprint Small Package Size 4x5mm
• RoHS Compliant and Green

Learn more about how our products can elevate your applications by contact our sales team.

Thank you for choosing Reed Semiconductor for innovative power management solutions!
