RS31310

RS31310 12V, 5A eFuse for Intelligent Power Path Protection

As 12V power rails continue to serve as the backbone of servers, networking equipment, storage systems, and industrial electronics, protecting these rails from overloads, short circuits, and fault conditions has become increasingly important. The RS31310 is a compact, integrated 12V eFuse that provides intelligent circuit protection while minimizing power loss, board space, and external component count.

Designed for distributed 12V power architectures, the RS31310 integrates a 25mΩ pass MOSFET, programmable current limiting, adjustable undervoltage lockout (UVLO), controlled output slew rate, and a fixed 15V overvoltage clamp into a compact 3 × 3 mm VSON-10 package. Supporting adjustable current limits from 2A to 5A, the device enables designers to tailor protection and startup performance for a wide range of applications while improving overall system reliability.

Intelligent Protection for Modern 12V Power Rails

Today’s systems require more than simple fuses or discrete MOSFET protection circuits. The RS31310 continuously monitors operating conditions and actively protects downstream circuitry against electrical faults before permanent damage can occur.

Integrated protection features include:

• Adjustable 2A to 5A current limit
• Fixed 15V overvoltage clamp
• Overtemperature protection
• Programmable input UVLO
• Adjustable output slew-rate control
• Logic enable input for power sequencing

Together, these features improve system robustness while reducing the number of external components required for reliable power-path protection.

Low-Loss Power Delivery

Power efficiency is critical even on lower-current rails. The RS31310 integrates a low 25mΩ power MOSFET that minimizes conduction losses and voltage drop while eliminating the need for an external pass transistor.

The highly integrated solution helps designers:

• Improve system efficiency
• Reduce heat generation
• Simplify PCB layout
• Lower BOM cost
• Increase overall reliability

Controlled Startup for Reliable System Operation

Large downstream capacitance can create significant inrush current during startup. The RS31310 allows designers to program the output slew rate using a single external capacitor connected to the dV/dt pin, providing smooth and predictable startup behavior.

Combined with programmable current limiting and UVLO, the device enables designers to:

• Reduce inrush current
• Prevent nuisance shutdowns
• Improve hot-plug performance
• Sequence multiple power rails
• Protect upstream power supplies

This flexibility makes the RS31310 well suited for distributed power systems where startup control is just as important as fault protection.

Optimized for High-Density System Designs

The RS31310 is designed for applications where PCB area is limited but reliable protection is essential.

Typical applications include:

• Server 12V distribution rails
• Networking equipment
• PCI and PCIe expansion cards
• Solid-state drives (SSD)
• Hard disk drives (HDD)
• Industrial control systems
• Embedded computing platforms
• Adapter-powered equipment

Its compact 3 × 3 mm VSON-10 package enables designers to integrate comprehensive protection without sacrificing valuable board space.

Choose the Right Reed Semiconductor eFuse

The RS31310 is part of Reed Semiconductor’s comprehensive eFuse portfolio, providing protection solutions from compact peripheral rails to high-current AI power systems.

Whether protecting a peripheral 5V rail or a distributed 12V power bus, Reed Semiconductor offers integrated eFuse solutions designed to improve reliability, simplify design, and reduce system cost.

Why Choose the RS31310?

The RS31310 combines intelligent protection, low power loss, and flexible configuration into a compact, easy-to-use solution for 12V power rails. With programmable current limiting, adjustable startup control, integrated overvoltage protection, and a low-resistance MOSFET, it helps designers build more robust and efficient power systems without the complexity of discrete protection circuits.
