RS86900 2.5V to 16V, 90A Half-Bridge Smart Power Stage
We are excited to announce the launch of the RS86900, a high-performance monolithic half-bridge designed to meet the demanding power needs of server, telecom, and graphic card applications. With its compact design and integrated features, the RS86900 offers efficiency, reliability, and protection in a small footprint.
Key Features
- Wide Operating Input Range: 2.5V to 16V for versatile application use.
- High Output Current: Delivers up to 90A max, 45A continuous output for robust performance.
- High Efficiency: Integrated high/low-side MOSFETs and drivers minimize losses and enhance system efficiency.
- Fast Operation Frequency: Up to 3MHz with a 5V input and 2MHz with a 12V input for flexible design choices.
- Protection Built-In: Includes over-current protection, over-temperature protection, and UVLO to ensure safe operation.
- Compact TLGA Package: 4mm x 6mm form factor for space-saving designs.
- Optimized to work with Reed multiphase controllers.
- RoHS Compliant and Green: Environmentally friendly and industry-compliant.
Product Overview
The RS86900 90A smart power stage is designed for space-constrained environments, offering high efficiency and powerful performance in a compact TLGA package. With an integrated power stage, including high/low-side MOSFETs and drivers, the RS86900 simplifies design and minimizes parasitic losses, making it ideal for server and telecom voltage regulators, graphic card core regulators, and power modules. Its high operating frequency and compatibility with 3.3V tri-state PWM input make it a versatile solution, while internal current sense and temperature sense features ensure precise control and monitoring. Additionally, its robust protection features, including cycle-by-cycle over-current limit and over-temperature protection, provide enhanced reliability in critical applications.
Applications
- Server and Telecom Voltage Regulators: Ensure high-efficiency power management in data centers and communication systems.
- Graphic Card Core Regulators: Provide robust power to handle graphic-intensive workloads.
- Power Modules: Deliver efficient power conversion in modular designs.
Discover the RS86900
The RS86900 90A smart power stage is the ideal choice for engineers looking for a compact, high-performance power solution. To learn more about how this device can enhance your systems, visit our website or contact our sales team.
Thank you for choosing Reed Semiconductor for your advanced power management solutions.
